NPT Active HPe
1 Door Digital Refrigerator, 670lt (-2/+10) - R290 - Class A
1-door refrigerator 670lt, -2+10°C, digital, AISI 304, R290, Class A
Suggested green version.
- Green Benefits
- Features
- Specifications
- Documents
- Accessories
- Energy savings: Reduce your electricity bill by 80%
* with Zanussi NPT Active HPe (Class A).
- Energy efficiency: Consumes less than 300 kWh/year for 504L storage, ensuring sustainability and cost savings.
- Storage capacity: Offers 50L more space than market equivalents with durable AISI 304 stainless steel construction.
- Smart performance: Frost Watch Control optimizes defrosting by minimizing temperature fluctuations, reducing bacteria, food waste, and energy consumption.
- Easy to use: Bluetooth app management and remote monitoring for seamless operation.
*Calculated on a 503lt (net volume) full·door refrigerated cabinet, replacing a class G appliance with a class A.
-
Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).
-
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
-
Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
-
Large digital white-digit display with cabinet temperature display and setting, and possibility to select the desired levels of humidity. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
-
Zanussi Professional Fridge Control APP make the life easier for our customers: - Monitor safety of preservation process thanks to HACCP data & alarms for precise control- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address- Quick operations: set the cabinet temperature/humidity/turbocooling and set date/hour
-
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to 30 days of event are kept in memory.
-
Tropicalized unit.
-
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
-
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
-
Optiflow: back to front forced air flow and removable air conveyors provide even temperature distribution and fast cooling in any conditions.
-
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
-
Rilsan coated grids for improved protection.
-
Interior base with rounded corners, pressed from a single sheet.
-
Lockable door.
-
Constructed from the highest quality AISI 304 Stainless steel.
-
Easy access to the main components for maintenance.
-
Stainless steel runners and supports easily disassembled.
-
The rounded internal corners, the easily removable runners, grids and air conveyors allow for ease of cleaning and high hygiene standards.
-
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Capacity:
- Number and type of grids (included): 3 - GN 2/1
Key Information:
- Net Volume: 503 lt
- Door hinges:
- External dimensions, Width: 740 mm
- External dimensions, Depth: 885 mm
- External dimensions, Depth with Doors Open: 1507 mm
- External dimensions, Height: 2080 mm
- Number and type of doors: 1 Full
- Type of external material: 304 AISI
- Type of internal material: 304 AISI
- Internal panels material: 304 AISI
- Number of positions & pitch: 44; 30 mm
- Gross capacity: 670 lt
- Type of model (EU Regulation. 2015/1094): vertical chilled
Sustainability
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power: 320 W
- Refrigerant weight: 110 g
- Energy Class (EU Reg. 2015/1094): A
- Yearly and daily energy consumption (EU Reg. 2015/1094): 299kWh/year - 1kWh/24h
- Climate class (EU Reg. 2015/1094): Heavy Duty (5)
- Energy Efficiency Index-EEI (EU Reg. 2015/1094): 22.30
Electric
- Supply voltage: 220-240 V/1 ph/50 Hz
- Electrical power max: 0.19 kW
Refrigeration Data
- Control type: Digital
- Refrigeration power at evaporation temperature: -10 °C
- Operating temperature min.: -2 °C
- Operating temperature max.: 10 °C
- Compressor power: 1/4 hp
- Operating mode: Ventilated
Data Sheet
Energy Label
Included Accessories
