NAU Maxi HPe
1 Door Digital Refrigerator, 670lt (-2/+10) R290 - Class A
111135

1-door refrigerator 670lt, -2+10°C, digital, AISI 304, R290, Class A

Where to buy
  • Green Benefits
  • Features
  • Specifications
  • Documents
  • Accessories
  • Energy savings: Reduce your electricity bill by 75%
    * with Zanussi NAU Maxi HPe (Class A).
  • Energy efficiency: Consumes less than 350 kWh/year for 504L storage, ensuring sustainability and cost savings.
  • Storage capacity: Offers 50L

more space than market equivalents with durable AISI 304 stainless steel construction.

*Calculated on a 503lt (net volume) full·door refrigerated cabinet, replacing a class G appliance with a class A.
  • Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.

  • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

  • Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).

  • IQ Defrost: fully automatic defrost starts only when ice is actually building-up in the evaporator.

  • Airflow: back to front forced air flow and removable air conveyors provide even temperature distribution and fast cooling in any conditions.

  • Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

  • 60 mm-thick insulation covering the evaporator can be easily removed with a single operation.

  • Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.

  • Provided with stainless steel A304 grids.

  • Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.

  • Easy serviceability thanks to the intuitive control panel with access via app.

  • Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • Tropicalized unit.

  • The rounded internal corners, the easily removable runners, grids and air conveyors allow for ease of cleaning and high hygiene standards.

  • Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.

  • Stainless steel runners and supports easily disassembled.

  • Easy access to the main components for maintenance.

  • Constructed from the highest quality AISI 304 Stainless steel.

  • Lockable door.

  • Interior base with rounded corners, pressed from a single sheet.

Capacity:
  • Number and type of grids (included): 3 - GN 2/1
Key Information:
  • Net Volume: 503 lt
  • Capacity: 670 lt / Bottle .75L Bordeaux
  • Door hinges:
  • External dimensions, Width: 740 mm
  • External dimensions, Depth: 860 mm
  • External dimensions, Depth with Doors Open: 1480 mm
  • External dimensions, Height: 2080 mm
  • Number and type of doors: 1 Full
  • Type of external material: 304 AISI
  • Type of internal material: 304 AISI
  • Internal panels material: 304 AISI
  • Number of positions & pitch: 44; 30 mm
  • Gross capacity: 670 lt
  • Type of model (EU Regulation. 2015/1094): vertical chilled
Sustainability
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power: 278 W
  • Refrigerant weight: 110 g
  • Energy Class (EU Reg. 2015/1094): A
  • Yearly and daily energy consumption (EU Reg. 2015/1094): 340kWh/year - 1kWh/24h
  • Climate class (EU Reg. 2015/1094): Heavy Duty (5)
  • Energy Efficiency Index-EEI (EU Reg. 2015/1094): 23.69
Electric
  • Supply voltage: 220-240 V/1 ph/50 Hz
  • Electrical power max: 0.19 kW
Refrigeration Data
  • Control type: Digital
  • Refrigeration power at evaporation temperature: -10 °C
  • Operating mode: Ventilated
Data Sheet
Energy Label
(316,8 KB)
(277,01 KB)
BIM/Revit
(904 KB)
Included Accessories
Quantity
Code
Description
Quantity: 3
Code: 881020
2/1GN grey rilsan grid with 2 runners
