NAU Maxi HPe
1 Door Digital Freezer, 670lt (-22/-15) - R290 - Class B
1-door freezer 670lt, -22-15°C, digital, stainless steel, R290, Class B
Suggested green version.
- Green Benefits
- Features
- Specifications
- Documents
- Accessories
- Energy savings: Reduce your electricity bill up to 67%
* with Zanussi NAU Maxi HPe (Class B).
- Storage capacity: Offers 50L more space than market equivalents with durable AISI 304 stainless steel construction.
*Calculated on a 503lt (net volume) full·door freezer cabinet, replacing a class G appliance with a class B.
-
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
-
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
-
Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.
-
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
-
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
-
Rilsan coated grids for improved protection.
-
Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.
-
Tropicalized unit.
-
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
-
Automatic defrost.
-
Easy serviceability thanks to the intuitive control panel with access via app.
-
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
-
Equipped with single phase electrical cable and Schuko plug for easy and fast installation.
-
Freezer model has operating temperatures that can be adjusted from -22 to -15 °C.
-
Right hinged full door.
-
Easy access to the main components for maintenance.
-
Stainless steel runners and supports easily disassembled.
-
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
-
Doors are self-closing and can be fully opened up to 180°.
-
Lockable door.
-
The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.
-
AISI 430 stainless steel internal structure and external panels.
-
Mounted on adjustable Stainless steel feet, with castors as an option.
Capacity:
- Number and type of grids (included): 3 - GN 2/1
Key Information:
- Net Volume: 503 lt
- Door hinges:
- External dimensions, Width: 740 mm
- External dimensions, Depth: 885 mm
- External dimensions, Depth with Doors Open: 1480 mm
- External dimensions, Height: 2080 mm
- Number and type of doors: 1 Full
- Type of external material: Stainless Steel
- Type of internal material: Stainless Steel
- Internal panels material: Stainless Steel
- Number of positions & pitch: 44; 30 mm
- Gross capacity: 670 lt
- Type of model (EU Regulation. 2015/1094): vertical frozen
Sustainability
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power: 707 W
- Refrigerant weight: 90 g
- Energy Class (EU Reg. 2015/1094): B
- Yearly and daily energy consumption (EU Reg. 2015/1094): 1380kWh/year - 4kWh/24h
- Climate class (EU Reg. 2015/1094): Heavy Duty (5)
- Energy Efficiency Index-EEI (EU Reg. 2015/1094): 34.92
Electric
- Supply voltage: 220-240 V/1 ph/50 Hz
- Electrical power max: 0.3 kW
Refrigeration Data
- Control type: Digital
- Refrigeration power at evaporation temperature: -23.3 °C
- Operating temperature min.: -15 °C
- Operating temperature max.: -22 °C
- Compressor power: 3/4 hp
- Operating mode: Ventilated
Data Sheet
Leaflets
Energy Label
Included Accessories
