NAU Maxi
1 Door Digital Refrigerator, 670lt (-2/+10) R290
110941

1-door refrigerator 670lt, -2+10°C, digital, AISI 304, R290

Fast range available in stock. (click to discover more)

Alternative green solution available.

Where to buy

Suggested
for you.

Go premium,
go green.

go to product

NAU Maxi HPe
1 Door Digital Refrigerator, 670lt (-2/+10) R290 - Class A
111135

1-door refrigerator 670lt, -2+10°C, digital, AISI 304, R290, Class A

  • Features
  • Specifications
  • Documents
  • Accessories
  • Cabinet fitted with up to 75 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).

  • Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.

  • Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.

  • 60 mm-thick insulation covering the evaporator can be easily removed with a single operation.

  • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

  • Rilsan coated grids for improved protection.

  • Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.

  • Tropicalized unit.

  • Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.

  • Automatic defrost.

  • Easy serviceability thanks to the intuitive control panel with access via app.

  • Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.

  • Equipped with single phase electrical cable and Schuko plug for easy and fast installation.

  • Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.

  • Right hinged full door.

  • Easy access to the main components for maintenance.

  • Constructed from the highest quality AISI 304 Stainless steel.

  • Stainless steel runners and supports easily disassembled.

  • Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.

  • Doors are self-closing and can be fully opened up to 180°.

  • Lockable door.

  • The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.

  • Mounted on adjustable Stainless steel feet, with castors as an option.

Capacity:
  • Number and type of grids (included): 3 - GN 2/1
Key Information:
  • Net Volume: 503 lt
  • Door hinges:
  • External dimensions, Width: 710 mm
  • External dimensions, Depth: 835 mm
  • External dimensions, Depth with Doors Open: 1480 mm
  • External dimensions, Height: 2050 mm
  • Number and type of doors: 1 Full
  • Type of external material: 304 AISI
  • Type of internal material: 304 AISI
  • Internal panels material: 304 AISI
  • Number of positions & pitch: 44; 30 mm
  • Gross capacity: 670 lt
  • Type of model (EU Regulation. 2015/1094): vertical chilled
Sustainability
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power: 278 W
  • Energy Class (EU Reg. 2015/1094): C
  • Yearly and daily energy consumption (EU Reg. 2015/1094): 713kWh/year - 2kWh/24h
  • Climate class (EU Reg. 2015/1094): Heavy Duty (5)
  • Energy Efficiency Index-EEI (EU Reg. 2015/1094): 49,67
Electric
  • Supply voltage: 220-240 V/1 ph/50 Hz
  • Electrical power max: 0.2 kW
Refrigeration Data
  • Control type: Digital
  • Refrigeration power at evaporation temperature: -10 °C
  • Operating temperature min.: -2 °C
  • Operating temperature max.: 10 °C
  • Operating mode: Ventilated
CAD Drawings
(106,18 KB)
Data Sheet
Energy Label
(314,49 KB)
(274,78 KB)
BIM/Revit
(1,22 MB)
Included Accessories
Quantity
Code
Description
Quantity: 3
Code: 881020
2/1GN grey rilsan grid with 2 runners
